HEXA X4040

Description

HEXA X4040

The HEXA X4040 Concrete Paving Mold stands out for its unique and innovative design, making it one of the most attractive options compared to conventional cement paving molds available worldwide. This mold, measuring 40×40 cm with a height of 4.5 cm and blade thickness of 6 mm, is made from durable ABS plastic. It allows for easy and skill-free landscaping of various spaces such as villas, apartments, parks, urban green areas, gardens, and more.

A notable feature of this mold is its ability to use colorful mortars, creating visually stunning and elegant pavements. The mold’s design is based on irregular geometric lines, enabling you to position the templates in different orientations to craft creative and appealing patterns. This template is a simple yet effective solution for paving walkways, villa yards, gardens, and green spaces. Compared to traditional methods like tiling or concrete pouring, it is faster and more cost-effective to implement.

The HEXA X4040 model also serves as an excellent alternative to conventional paving methods such as tiling, concrete pouring, or using ready-made concrete pavers. It is particularly suitable for public spaces like parks and urban green areas, delivering higher quality, longer-lasting, and more aesthetically pleasing pavements than traditional techniques.

Features HEXA X4040

• Durable Structure: Made from highly compressed and durable ABS polymer, this mold offers exceptional resistance to various weather and environmental conditions.
• Long Lifespan: With proper maintenance, the mold is reusable and can serve as a permanent tool for contractors.
• Impact Resistance: The HEXA X4040 paving mold has high tolerance against impact and pressure, ensuring it does not crack or break easily.
• Superior Abrasion Resistance: High-quality polymers used in its production make it highly resistant to wear and tear from mortar and concrete.
• Non-Adhesive Surface: Concrete and mortar do not stick to the mold during removal or application.
• High Durability: The mold resists breaking or chipping during mortar pouring or removal after the initial set.
• Flexible Design: Allows the use of colorful mortars within its cells to create aesthetically pleasing paving designs.
• Easy Cleaning: The mold can be cleaned easily with water and a brush, without requiring special acidic detergents.
• No Need for Subbase Preparation: This mold can be used on uneven and sloped surfaces without the need for extensive leveling or subbase work.
• Enhanced Aesthetics: Offers the option to plant grass, greenery, or fill the spaces between cells with pebbles to beautify the surroundings further.
• Ergonomic Design: Its user-friendly design minimizes hand fatigue during extended use.
• Accurate Markers: Clear markers on the mold make reading dimensions and measurements simple.
• Standard Dimensions: Designed with precise and standard measurements, making it suitable for a wide range of construction and industrial projects.



More products: garden pavement mold



Hexa X4040 Concrete Pavement Mold Installation Guide

For paving with plastic molds, selecting the right cement mortar and adhering to specific physical requirements is crucial. The mortar mix should have a grade of no less than 300, with 350 recommended for optimal results.

One of the key considerations is using mortar or concrete with a slump of 4 to 6. Using overly fluid concrete can increase the mold removal time and slow down the workflow.
Before starting, it’s recommended to lubricate the molds with diesel or suitable oil. Arrange the Hexa X4040 molds side by side and saturate the base of the molds with fresh water to prevent rapid absorption of water by the ground before the mortar sets.

Mortar Application Steps:

1. Fill the cells of the mold with mortar using a trowel or spatula and smooth the surface.
2. For different colored mortars, use smaller trowels for precise application within the cells.
3. After filling the cells, tap the mold surface gently to compact the mortar and create a vibrated effect.

Curing and Mold Removal Timing:

• Depending on weather conditions, allow the mortar to set for 2 to 3 hours.
• Remove the molds vertically to avoid damaging the edges of the patterned concrete.

Post-Mold Removal Process:

• Once the molds are removed, cure the surface by sprinkling water for at least 3 days.
• Based on the temperature and the concrete mix, the surface can be walked on 24 to 48 hours after mold removal. After 7 days, it will be ready to withstand heavy loads, such as vehicle traffic.

Mold Maintenance:
After completing the work, wash the molds with water and a brush, dry them, and store them in a suitable location to ensure durability.

Package

1 pcs in box
