HEXARC X3550

Description

HEXARC X3550

The HEXARC X3550 concrete paving mold is an innovative and unique tool among all available templates. Made of ABS plastic, this mold measures 35 x 50 cm, with a height of 4.5 cm and a blade thickness of 6 mm. With this mold, various areas such as villa and apartment yards, gardens, parks, and urban green spaces can be easily paved without requiring any special skills.

These templates not only simplify the process but also allow the use of colorful mortars for surface beautification. The geometric design of this mold is composed of irregular arcs, creating a distinctive appearance for paving. Using this mold for paving walkways in environments such as gardens, villas, and parks is the easiest and most practical method for surface coverage, delivering faster performance and more attractive results compared to traditional methods like concreting or tiling.

The HEXARC X3550 paving template is an economical and efficient choice for landscaping public spaces such as parks. It serves as a suitable alternative to other common methods, including pre-made pavers or concreting, and delivers significantly superior results compared to all these techniques.

Features HEXARC X3550

• The HEXARC X3550 paving mold is made of durable and dense ABS polymer, offering high resistance to various weather and environmental conditions.
• This plastic mold, due to its high reusability, can serve as a permanent tool for contractors if properly maintained.
• It is highly resistant to physical impacts and pressure, making it unlikely to crack or break easily.
• The use of ABS plastic in its construction ensures excellent resistance to wear caused by mortar and concrete.
• The mold prevents concrete from sticking to it during mortar pouring or mold removal.
• The HEXARC X3550 mold remains intact during use, including mortar pouring and removal after initial setting, without any cracking or edge chipping.
• It allows the use of different colored mortars in the mold cells, enhancing design variety and aesthetic appeal.
• Easily washable with water and a brush, without the need for any special acidic cleaners.
• Does not require precise surface leveling or slope adjustment before paving with this mold.
• Enables cementitious coverage even on uneven or sloped surfaces without the need for special preparation.
• Supports combining multiple paving mold designs for a single space to enhance visual beauty.
• Allows for planting grass, greenery, or placing gravel between paving sections to decorate the environment.
• Its precise design ensures the pavers are installed with high alignment and consistency.
• The mold is lightweight and conveniently designed, making it easy to transport and use in various locations.



More products: garden pavement mold



How to use HEXARC X3550

One of the most important aspects of paving surfaces with concrete molds is ensuring the appropriate properties of the cement mortar before pouring it into the molds. The mortar should have a cement ratio of at least 300; however, for better quality, a ratio of 350 is recommended.

The mortar used to fill the molds should have a slump between 4 and 6. If the concrete’s consistency exceeds this range, the setting time and the process of removing the mold will take longer, potentially slowing down the workflow.

To prevent concrete from sticking to the molds, it is recommended to coat the inner surfaces of the molds with form-release oil, diesel, or similar materials before pouring the mortar.

Arrange the available molds side by side based on the number available. Before pouring the mortar, moisten the bottom of the molds with fresh water to prevent the molds from absorbing water from the mix and ensure better initial setting quality.

Using a trowel, pour the mortar into the mold cells and level the surface. If you intend to use different colored mortars, it is recommended to use smaller trowels for more precision and accuracy.

After filling all the cells, lightly tap the surface of the mold with the trowel or your hand to compact and settle the mortar.

Depending on the weather conditions, the mortar should remain in the mold for 2 to 3 hours to achieve its initial setting. When removing the mold, lift it vertically to avoid damaging the concrete or causing edge chipping.

Once the molds are removed, keep the paved surface moist by spraying water for at least three days to properly cure the concrete.

Depending on the ambient temperature and the concrete mix design, the surface can be walked on after 24 to 48 hours. After 7 days, it will be ready to bear heavy loads such as vehicle traffic.

Finally, clean the molds with water and a brush, dry them, and store them in an appropriate place for future use.

Package

1 pcs in box
