HEXARC X4040

Description

HEXARC X4040

The HEXARC X4040 concrete paving mold is a unique product compared to all other molds available in Iran and worldwide. This mold, measuring 40×40 cm with a height of 4.5 cm and a thickness of 6 mm, is made of highly durable ABS plastic. With this mold, it is easy to pave areas such as villa yards, apartments, parks, gardens, and green spaces without requiring any special skills. Additionally, this mold allows the use of colored mortars to create visually stunning and diverse paving designs.

The design of this mold is inspired by irregular arcs, making it an excellent choice for paving pathways and various spaces. Using the HEXARC X4040 mold for flooring in gardens, villas, and green spaces is a superior alternative to traditional methods like concrete pouring or mosaic work. This mold is also ideal for urban and public areas such as parks, delivering a more beautiful and striking result compared to other methods.

Features HEXARC X4040

• This mold is made of compressed and highly durable ABS polymer, offering excellent resistance to various weather conditions.
• With a high repetition rate and proper maintenance, it can serve as a permanent tool for professionals.
• It is highly resistant to impacts and physical forces, ensuring it doesn’t easily crack or break.
• Thanks to the use of ABS material, the mold offers excellent abrasion resistance against concrete and mortar.
• No adhesion occurs between the mold and concrete during mortar pouring or mold removal.
• The HEXARC X4040 mold does not crack or chip during mortar pouring or when removed after the initial set.
• It allows for the use of various colors in each cell of the mold, creating unique and visually appealing designs.
• Cleaning the mold is easy with water and a brush, without requiring any special acidic detergents.
• There is no need for complete surface leveling or preparation before paving.
• The mold is capable of creating cement overlays and walkways on uneven or sloped surfaces.
• Multiple types of molds can be combined to enhance the aesthetic appeal of any space.
• It supports planting grass or adding pebbles between the paving cells to enhance the environment’s beauty.
• Manufactured with high precision and in compliance with industrial standards, ensuring accuracy in various operations.
• Equipped with clear and precise markers, making it easier to read dimensions and measurements.
• Its appropriate weight design simplifies transportation and usage on-site in different projects.



More products: garden pavement mold



How to use

To execute paving with plastic molds, it is essential to consider environmental conditions and use appropriate cement mortar. The mortar mix should have a grade of at least 300, and for optimal results, a grade of 350 is recommended.

1. Before starting, grease the molds with oil or diesel to prevent the mortar from sticking to the mold.
2. Arrange the HEXARC X4040 molds neatly side by side, based on the number of molds available.
3. Thoroughly wet the molds with fresh water to prevent them from absorbing moisture from the mortar and allow adequate time for initial setting.
4. Use a trowel to evenly pour the prepared mortar into the cells of the mold and level the surface.
5. If you plan to use different colors in the cells, smaller trowels can help ensure more precise mortar application.
6. After filling the cells, gently tap the surface of the mold with your hand or a trowel to naturally vibrate and compact the mortar.
7. Depending on the weather conditions, allow the mortar to remain in the mold for 2 to 3 hours until it reaches its initial set.
8. When removing the molds, lift them vertically to avoid damaging or chipping the patterned concrete.
9. After demolding, keep the surface moist for at least 3 days by sprinkling water (curing) to prevent rapid drying of the concrete.
10. Based on the ambient temperature and the concrete mix design, the surface can be walked on after 24 to 48 hours and will be ready to withstand heavy loads, such as vehicle traffic, after 7 days.
11. Once the work is complete, clean the molds with water and a brush, dry them, and store them in a suitable location.

Package

1 pcs in box
